PN16 Ball Check Valve

Valve Type Ball Check Valve (Free Floating Ball Design)
Body Material Ductile Iron (ASTM A536 Grade 65-45-12 / GGG-50)
Ball Material Carbon Steel + Fully Lined EPDM
Nominal Size 2″ – 12″ (DN50 – DN300)
Pressure Rating Class 125 / Class 150 / PN10 / PN16
End Connection Flanged (FF / RF) / Threaded (NPT / BSP)
Design Standard API 594 / Manufacturer Standard

Description

Technical Datasheet: Ball Check Valve

(Ductile Iron Body / Carbon Steel Ball Lined with EPDM)

General Information

Item	Standard Configuration	User Specification / Remarks
Valve Type	Ball Check Valve (Free Floating Ball Design)
Body Material	Ductile Iron (ASTM A536 Grade 65-45-12 / GGG-50)
Ball Material	Carbon Steel + Fully Lined EPDM	Free Floating Ball
Nominal Size	2″ – 12″ (DN50 – DN300)
Pressure Rating	Class 125 / Class 150 / PN10 / PN16
End Connection	Flanged (FF / RF) / Threaded (NPT / BSP)
Design Standard	API 594 / Manufacturer Standard
Face-to-Face	API 594 Short Pattern / Manufacturer Standard
Flange Dimension	ASME B16.1 (Class 125) / ASME B16.5 (Class 150) / EN 1092-2
Inspection & Test	API 598 / EN 12266-1

Bill of Materials (Main Components)

No.	Part Name	Standard Material	Optional Material / Remarks
1	Body	Ductile Iron (ASTM A536 65-45-12)	Epoxy Coated (Internal/External)
2	Cap / Cover	Ductile Iron (ASTM A536 65-45-12)	Epoxy Coated
3	Ball	Carbon Steel + EPDM Lined (Fully)	WCB / WCB + EPDM (Vulcanized)
4	Seat	Integral (Body Seat)	EPDM Lined / Buna-N
5	Ball Stop / Cage	Ductile Iron / Carbon Steel	Retains ball in flow path
6	Gasket	Compressed Non-Asbestos / EPDM
7	Cover Bolt	Carbon Steel (Zinc Plated) / Stainless Steel	ASTM A307 / A193-B8

Technical Parameters & Performance

Item	Specification
Medium	Water, Wastewater, Slurries, Sewage, Fluids with Solids
Operating Temp.	-20°C ~ +100°C (EPDM Lining)
Max Operating Pressure	Up to 200 psi / 16 bar (Depending on pressure class)
Flow Direction	Horizontal or Vertical Upwards (Ball lifts to open)
Sealing	Bubble Tight Shut-Off (Soft-Seated)
Lining Material	EPDM (Ethylene Propylene Diene Monomer) – Excellent for water, abrasion resistance, and mild chemicals
Ball Action	Free floating ball lifts off seat when flow enters, drops back to seal when flow reverses
Features	Non-slam operation, ideal for dirty fluids and slurries

Test Pressure (Reference: Class 150 / PN16)

Pressure Rating	Shell (Hydrostatic)	Seat (Hydrostatic)	Low Pressure Seat (Air)
Class 150	425 psi (2.9 MPa)	315 psi (2.2 MPa)	50 – 80 psi (0.34 – 0.55 MPa)
PN16	24 bar (2.4 MPa)	17.6 bar (1.76 MPa)	0.6 bar (0.06 MPa)
(Note: Specific values shall be performed per API 598 / EN 12266.)

Dimensions & Weight (Reference: Class 150 Flanged, Short Pattern)

NPS	L (Face-to-Face) mm	H (Approx.) mm	Weight (kg) Approx.
2″	150	95	8
3″	180	120	14
4″	200	145	22
6″	240	195	40
8″	280	240	65
10″	320	290	95
(Note: Dimensions may vary by manufacturer; please refer to certified GA drawing)

Special Requirements / Options

Ball Material: Carbon Steel Lined EPDM / Stainless Steel Lined EPDM / Solid EPDM Ball
Soft Seat Material: EPDM / Buna-N / Viton / Neoprene
Lining Color: Black / Custom
Test Certificate: EN 10204 3.1
Coating: External Epoxy Coating (Min. 250 microns)
Special Cleaning: For Potable Water (NSF/ANSI 61)
Accessories: Drain Plug / Vent Plug

Note: This datasheet is prepared for a Ball Check Valve with EPDM lined ball. Suitable for handling fluids containing suspended solids, slurries, and wastewater where a traditional swing or lift check valve may clog or fail.
