B148 C95800 Aluminum Bronze Lugged Butterfly Valve 2″ 150LB

Description

Aluminum Bronze Lugged Butterfly Valve

Size: 2″ | Pressure Rating: 150LB

Premium Material Construction:

• Body & Disc: C95800 Aluminum Bronze (superior seawater/corrosion resistance)
• Stem: Monel K500 (exceptional strength & chloride stress corrosion cracking resistance)
• Seat: Viton® (excellent chemical/weather resistance, -20°C to 120°C)
• Operation: Lever or Gear Actuator (selectable for manual/process control)

Engineered Design Features:

• Type: Concentric, Pinless Design (reduced wear, smooth 90° operation)
• Connection: Full Lugged (allows pipeline end removal without valve disassembly)
• Sealing: Zero-Leakage Viton® Seat (bubble-tight shutoff per API 609)
• Marine-Grade: Ideal for saltwater/offshore applications (NACE MR0175 compliant)

Performance Specifications:

• Temp Range: -20°C to +120°C
• Standards: API 609, MSS SP-67
• Applications: Seawater systems, chemical processing, marine/shipbuilding

Key Advantages:

✓ Corrosion Champion – C95800+Monel combo withstands harsh marine environments
✓ Maintenance-Friendly – Pinless design eliminates stem wear points
✓ Dual Operation – Lever (quick shutoff) or Gear (precise flow control) options
✓ Installation Flexibility – Lugged ends simplify piping maintenance

(Optional: Locking Device, Position Indicator, or EPDM Seats available)
