Monel Needle Globe Valve Ferrule End

Description

Technical Datasheet: Monel Needle Valve (Double Ferrule Tube Fitting)

1. General Product Data

2. Pressure & Temperature Ratings

Note: Pressure ratings are temperature-dependent and decrease at the upper temperature limits.

3. Material of Construction (Wetted Parts)

4. Dimensional & Flow Data (Typical Values)

Note: Dimensions vary based on connection size.

5. Features & Design

• Packing Below Threads: Packing is located below the stem threads to prevent system media from coming into contact with the threads, reducing corrosion and fugitive emissions.
• Non-Rotating Stem Tip: Prevents galling (scoring) of the seat and stem tip, ensuring leak-tight shut-off and extending cycle life.
• Live-Loaded Packing: (Optional/Standard on some series) Utilizes a spring (Belleville washer) to maintain constant pressure on the packing, compensating for wear and temperature changes.
• Panel Mountable: Standard feature on most forged body designs.
• Safety Backstop: A handle stop prevents over-tightening and potential stem blowout.

6. Applicable Standards & Testing

• Design Standard: Designed to meet ANSI B16.34 / ASME standards.
• Inspection: Each valve is factory-tested for bubble-tight leakage at both the seat and the packing.
• Cleaning: Standard cleaning per ASTM G93 (or equivalent) for instrumentation and oxygen service (Special cleaning SC-11 available).
• Compliance: NACE MR0175 / ISO 15156 compliance available upon request for sour gas service.

7. How to Order (Typical Configuration Code)

When ordering, specify the configuration as follows:

Ordering Example: 2219-G8M (2219 Series, Gyrolok 1/2″, Monel Body)
