Closed Die-Forged Bellow Seal Globe Valve

Description

Forged Steel Bellow Seal Globe Valve

Size: DN50 | Pressure Rating: PN63

Key Material Specifications:

• Body: ASTM A105N Forged Carbon Steel (high-pressure durability)
• Disc: A105N + 13Cr Hardfacing (enhanced wear & erosion resistance)
• Stem: ASTM A182 F6 (high-strength martensitic stainless steel)
• Seat: 13Cr Stainless Steel (reliable sealing under high pressure)
• Bellows: 304 Stainless Steel (corrosion-resistant, leak-proof design)
• Operator: Handwheel (HW)

Design Features:

• Construction: Bolted Bonnet (BB), Outside Screw & Yoke (OS&Y)
• Sealing System: Double-sealed with bellows + gland packing (zero emissions)
• Connection: RF Flange (EN1092 standard for secure installation)
• Surface Finish: Epoxy Coating (robust corrosion protection)

Operating Conditions:

• Temperature Range: -20°C to +120°C
• Applications: Ideal for steam, oil & gas, and chemical systems requiring emission-free shutoff.

Key Advantages:

• 100% Leakage-Free – Metal bellows prevent stem leakage (API 622 compliant).
• Long Service Life – Hardfaced trim resists erosion in high-P/T conditions.
• Low Maintenance – OS&Y design allows easy maintenance without valve removal.
• Safe & Compliant – Suitable for fugitive emission control (ISO 15848-1).

(Custom trim materials and NACE MR0175 options available.)
