Api 608 2-Piece Trunnion Mounted Ball Valve Cast Steel Full Bore

SAMPLE SPECIFICATIONS
SIZE:8″
RATING:150LB
BODY AND BONNET : ASTM A216 WCB
BALL: ASTM A182 F316
STEM: ASTM A182 F316
SEAT: ASTM A182 F316 COLLAR WITH DEVLON INSERT
SPRING: INCONEL X-750
ACTUATION: GEAR UNIT

GENERAL DESIGNED SPECIFICATION

Size: 2″~8″.
Pressure Rating: 150LB~4500LB
Design Temperature: -196℃~800℃
General applications: water, oil , gas
Design & Manufacture: API 6D , ASME B16.34 are basic,other norms could be used according to orders.
F TO F dimensions: API 6D, ASME B16.10, BS EN 558
Connection: RF AS PER ASME B16.5, EN 1092, JIS 5K-20K. BW, RTJ are available.
Safety design: anti-static, fire proof, anti-blow out stem.
Additional: Double block and bleed, TRUNNION.

TYPICAL MATERIAL LIST

BODY: ASTM A216 WCB/WCC, ASTM A217 WC6/WC9/C5/C12/C12A/CA15, ASTM A352 LCB/LCC, A351 CF8/CF8M/CF3/CF3M, A995 4A/5A, C83600/C95400/C95800, MONEL K400/K500, H-276, INCONEL 625/718.

BALL: ASTM A105, ASTM A182 F304/F304L/F316/F316L/F6A/F11/F22/F91/F51/F53/F55, A694 F60, C83600/C95400/C95800, MONEL K400/K500, H-276, INCONEL 625/718

STEM: A182 F6A, F304, F304L, F316, F316L, F51, F53,17-4PH, XM-19, C95400, C95800, C83600, INCONEL 625, INCONEL 718, MONEL K400, MONEL K500, H-276

SEAT COLLAR:A182 F6A, F304, F304L, F316, F316L, F51, F53,17-4PH, XM-19, C95400, C95800, C83600, INCONEL 625, INCONEL 718, MONEL K400, MONEL K500, H-276

SEAT INSERT: RPTFE, DEVLON,NYLON, MOLON, PCTFE, PEEK ETC.

SPRING: INCONEL X-750

OPERATOR: LEVER OR GEAR

OTHER SPECIAL MATERIALS ARE AVAILABLE TO CUSTOMIZE.

TEST AND INSPECTION

Inspection and approval norm: API598, API6D.

QUALITY CONTROL

100% Chemical analysis and mechanical test with raw materials of each heat numbers.
100% DPT test with the castings, partly MT or UT test, RT is always available if required.
100% hydraulic test with the shell and seal and low pressure air test.

GUATANTEE

SAVVY VALVES provide 12 months service life at least, free spares and maintenance instruction will be provided when required.

HOT SALE PRODUCTS

For over 10 years, we have been a leading supplier of industrial valves for major global projects in water supply, oil & gas, and desalination.

What Makes An API 608 2-Piece Trunnion Mounted Ball Valve Cast Steel Full Bore Ideal For Flow Control?

The API 608 2-piece trunnion mounted ball valve cast steel full bore is a highly reliable solution for applications requiring unrestricted flow and secure shut-off, such as oil and gas pipelines, petrochemical systems, and industrial processing lines. Its full bore design allows media to pass through with minimal pressure drop, making it ideal for pigging operations and reducing energy loss. The trunnion-mounted ball is anchored at both ends, which reduces friction and ensures tight sealing under high-pressure conditions. Cast steel construction provides excellent mechanical strength and corrosion resistance, while the 2-piece body design offers simplified maintenance and easy access to internal components. Certified to API 608, this valve meets strict performance and safety standards, ensuring consistent operation in critical systems. With low operating torque and compatibility with various actuators, it supports both manual and automated control, making it a dependable choice for demanding flow control applications.
